Jacob Aluminum is a leading manufacturer of quality aluminum products in Midland, UK. Specializing in a wide range of aluminum alloys, we offer customized solutions to meet the needs of industries such as construction, automotive and industrial. Our aluminum 5754 angles are made from a premium-grade material, providing corrosion resistance, strength and versatility. These angles are perfect for applications where durability and performance are important. With a commitment to accuracy, timely delivery and competitive prices, Jacob Aluminum is your trusted partner for all aluminum related needs in the UK.
Aluminum 5754 angle is a non-thermal alloy made primarily from aluminum, with magnesium as the major constituent (2.6–3.6%). It also contains trace elements such as manganese (0.5–1.0%), chromium (0.05–0.2%), silicon, iron and copper. This alloy is known for its excellent corrosion resistance and excellent weldability, especially in marine environments. Mechanical properties of aluminum 5754 include tensile strength of 200 to 290 MPa, yield strength of 150 to 220 MPa, and elongation of 15–25% Its hardness is usually between 50 and 75 HB.
Standards : ASTM B221 / B211 ASME SB221 / SB211, EN573, EN485, AMS 4003, AMS 4102
Temper : O,H12,H14,H16,H18,H19,H22,H24
Standard : ASTM, ASME, AMS, GB/T, JIS
Thickness : 50 mm to 6000 mm Long
Size : 3mm* 20mm* 20mm~ 12mm* 100mm* 100mm
Length : 1 To 6 Meters, Custom Cut Length
Finish : Mill, Customer specific finish
Surface : Anodize, powder coating, electrophoresis, PVDF coating, wood grain painting, matted, etc
| Mg | Mn | Si | Cu | Fe | Cr | Zn | Ti | Cu | Other (Each) | Others (Total) | Al |
| 2.60 – 3.60 | 0.0 – 0.50 | 0.0 – 0.40 | 0.0 – 0.40 | 0.0 – 0.30 | 0.0 – 0.20 | 0.0 – 0.15 | 0.0 – 0.10 | 0.0 – 0.05 | 0.0 – 0.05 | 0.0 – 0.15 | Balance |
| Proof Stress | Tensile Strength | Elongation at 50 mm | Hardness Brinell |
| 80 Min MPa | 190 – 260MPa | 12 Min % | 52 HB |
| UNS | EN | DIN | ISO | USA | WNR |
| A95754 | EN AW-5754 | AlMg3 | AlMg3 | AA5754 | 3.3535 |
Jacob Aluminium based in Midland, UK is a renowned manufacturer and supplier of premium aluminium products, including Aluminium Bars, Sheets and Plates, Coils, Chequered Plates, Wires, Pipes, Fittings, Flanges, Forging, Circle, Angles. With a commitment to delivering exceptional quality and service, we cater to diverse industries, offering reliable solutions tailored to specific requirements. Our products are known for their superior strength, corrosion resistance, and precise dimensions. We focus on customer satisfaction by providing an extensive range of aluminium bars designed for structural, industrial, and decorative applications.
Yes, we offer custom sizes for Aluminium 5754 Angles to meet specific project needs. Our team at Jacob Aluminium is committed to providing customized solutions for all your requirements. For more details, contact us at sales@bassamaluminium.com
Aluminum 5754 angles are widely used in applications where corrosion resistance, strength and lightness are required. The most common application is marine environments for boats and ships, as the compound is resistant to salt water. Because of its resistance to corrosion and weld resistance, it is also used in the manufacture of tanks, pressure vessels and pipelines, especially for the chemical and food processing industry in addition to angle 5754 in automobiles, building materials and construction in the structure of the. The durability of the alloy, combined with its ease of forming and welding, makes it ideal for these applications.
